2011-14 Ford F-150 (5.0 4V) ProCharger HO Intercooled System with P-1SC-1
2011-14 Ford F-150 (5.0 4V) ProCharger HO Intercooled System with P-1SC-1
SKU:
PROC1FV211-SCI-5.0Category:
2011-2014 F-150 (5.0, 6.2 4V)Brand:
100% original guarantee
Return within 30 days
Free delivery on all orders
70% HP GAINS WITH STOCK ENGINES ON PUMP GAS!
ProCharger is thrilled to unveil a new product in our diverse truck and SUV range—a complete air-to-air intercooled supercharger system tailored for the hardworking and adventurous 2011-14 Ford F-150 trucks equipped with the 5.0L 4V engine. These supercharger kits are engineered to deliver the highest power output per psi of boost available, with the HO Intercooled System achieving an impressive 45-55% increase in power using just 6-7 psi and factory fuel injectors, all while operating on otherwise stock engines with high-quality pump gas. The new HO Intercooled System features a shared-drive for the P-1SC-1 supercharger and a robust 3-core intercooler. For those looking for even greater performance, the Stage 2 systems for the 5.0L 4V F-150s can provide power gains of up to 60-65% with 8-9 psi, larger fuel injectors, and the Stage 2 intercooler.
Exclusive features of the ProCharger 5.0L F-150 truck kits include the self-contained ProCharger P-1SC-1 supercharger, a large front-mounted 3-core air-to-air intercooler, an option for a helical gearset, a variety of air inlet designs, and choices for supercharger and bracket finishes (satin, polished, or the new black finish).
ProCharger’s innovative self-contained supercharger oiling design removes the necessity for external oil lines or tapping into the engine’s oil supply, simplifying installation while ensuring optimal lubrication and lower supercharger oil temperatures.
The standard ProCharger P-1SC-1 supercharger included in the F-150 systems can also be upgraded with a helical gearset for quieter operation. ProCharger is the only manufacturer to provide this option for both the standard P-1SC-1 supercharger and the higher-output D-1SC supercharger.
HO Intercooled System
• 45-55% HP gain
• 6-7 psi boost
• P-1SC-1 supercharger, satin finish
• 3-core air-to-air intercooler
• 8-rib dedicated drive
• ProFlow blow-off valve
• Rear-facing air inlet
• Includes tuning and handheld programmer
ECM code required on hand held programmer applications
The computer code on the 2004+ F-150s should be located on the ECU under the hood on the passenger side near the firewall. You may need to remove a plastic covering to find the computer module and the white sticker with the code. It is a 4 character code with 3 letters and 1 number (Code is not P221).
| ProCharger | |
|---|---|
| Finish | Satin (Standard), Black, Polished |
| Bracket Finish | Satin (Standard), Black, Polished |
| Uncategorized | |
| Brand | ProCharger |
| Vehicle Year Selection | 2011, 2012, 2013, 2014 |
| Vehicle VIN# | VIN # |
| ECM Code | ECM Code |
| Drive Selection | 2WD, 4WD |
| Kit Upgrades | Helical Gearset (silent gears), Forward Facing Air Inlet (Stage II ONLY), Extra Oil (3 pack), Supercharger Upgrade (P-1X), Air-to-Air Race Intercooler Upgrade |
| Coyote Crank Support | No, Yes |
| Coyote Crank Support Finish | Satin (Standard), Black, Polished, No Crank Support |
| Shipping Details: | |
| Weight: | 4.44 lb |
| Length: | 1.0 in |
| Height: | 1.0 in |
| Width: | 1.0 in |
